R640
1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structure.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.


SPECIFICATIONS

Item

R640 Series

R640 Series

R640 Series

Pixel Pitch

1.667mm

2mm

2.5mm

LED Encapsulation

SMD1212

SMD1515

SMD2121

Scan Mode

1/64 Scan

1/40 Scan

1/432 Scan

Pixel Per Sq.m

360,000 Pixel

250,000 Pixel

160,000 Pixel

Module Size(W*H)

320*160mm

320*160mm

320*160mm

Brightness(Nits)

800

1000

1100

Install/Maintenance

Front Serviceable

Cabinet Material

Die Casting Aluminum

Cabinet Size(W*H*D)

640*480*60mm

Color Temperature

7KG/Piece

Refresh Rate

1920hz-3840hz

Color Temperature

6500K ±500(Adjustable)

Gray Scale

14-16bits

Average Power Consumption

100Watt/㎡

Max Power Consumption

200Watt/㎡

IP Protection

IP43

Operating Temperature

-20°C to 50°C

Working Voltage

100-240Volt(50-60hz)


GALLERY
